Check Out Our High-Quality A2L Brewery Chiller Line
Exceptional Cooling Performance for Your Brewing Applications! Our air-cooled chillers are available in both packaged and split system configurations, offering versatile solutions for indoor or outdoor installations based on your operational requirements. New A2L complaint refrigerants are both cost effective and more environmentally friendly. Both low in toxicity and flammability, the R454C and R454A units are perfect for your brewing future.
Brewery Chiller Data sheets for each A2L refrigerant
Brewers Association Member
Your Dedicated Brewery Chiller Supplier
At J&M Fluidics, we recognize that every brewery has unique cooling requirements. That’s why we manufacture a high-quality line of brewery chillers specifically designed to deliver exceptional cooling performance and reliability. Tailored exclusively for your brewing applications. Forget off-the-shelf solutions; our chillers are built to meet your exact specifications.
Advanced Features for Optimal Brewing Performance
Our brewery chillers are equipped with cutting-edge technology that ensures seamless operation and unparalleled efficiency:
User-Friendly Control
Each unit includes a state-of-the-art HMI touch screen control system that integrates flawlessly with our programmable Logic Controller (PLC) and custom software—making operation simple and intuitive.
Quality Components
Built with durable stainless steel tanks, stainless steel process pumps, and stainless steel brazed plate evaporators, our chillers are designed for longevity and performance. The robust painted packaged unit not only enhances durability but also complements your brewery’s aesthetic.
Commitment to Excellence
At J&M Fluidics, we pride ourselves on our unwavering commitment to excellence. Every brewery chiller undergoes an extensive factory performance test before leaving our facility, ensuring that you receive a product that meets the highest quality standards. This rigorous testing process guarantees optimal functionality and reliability right from the start.
We're Here to Help
Choosing the right brewery chiller is essential for your brewing operation. If you need assistance or have questions about which chiller would best suit your needs, don’t hesitate to reach out. Our knowledgeable team is here to guide you every step of the way, ensuring you find the perfect solution for your brewery.
Our Full Line of R454C J&M Brewery Chillers
Single and Dual Circuit Packaged Chillers with Insulated Stainless-Steel Tank
| Chiller System | Brewery Model | Capacity | Tank Capacity (Gallons) | Dimensions (L x W x H) Inches | Ship Weight (LBS) | |
|---|---|---|---|---|---|---|
| 28°F Glycol / 90°F Ambient | 33°F Glycol / 90°F Ambient | |||||
| 1 HP | PZATB1S | 6,900 | 7,800 | 20 | 36 x 34 x 68 | 685 |
| 3 HP | PZATB3S | 21,300 | 23,900 | 20 | 36 x 34 x 68 | 690 |
| 4.5 HP | PZATB4.5S | 31,200 | 35,000 | 50 | 46 x 34 x 70 | 800 |
| 5.5 HP | PZATB5.5S | 37,100 | 41,500 | 50 | 46 x 34 x 70 | 800 |
| 9 HP | PZATB9S | 64,200 | 72,000 | 80 | 75 x 34 x 75 | 1300 |
| 11 HP | PZATB11S | 118,600 | 88,700 | 80 | 75 x 34 x 75 | 1400 |
| 9 HP | PZATB9D | 62,400 | 70,000 | 80 | 75 x 34 x 75 | 1375 |
| 11 HP | PZATB11D | 74,200 | 83,000 | 80 | 75 x 34 x 75 | 1475 |
| 18 HP | PZATB18D | 128,400 | 144,000 | 120 | 85 x 40 x 75 | 1985 |
| 22 HP | PZATB22D | 237,200 | 177,400 | 120 | 75 x 66 x 76 | 2500 |
Single and Dual Circuit Split-System Chillers with Insulated Stainless-Steel Tank
| Chiller System | Brewery Model | Capacity | Tank Capacity (Gallons) | Dimensions (L x W x H) Inches | Ship Weight (LBS) | |
|---|---|---|---|---|---|---|
| 28°F Glycol / 90°F Ambient | 33°F Glycol / 90°F Ambient | |||||
| 1 HP | IEZATB1S | 6,900 | 7,800 | 20 | 36 x 34 x 68 | 685 |
| 3 HP | IEZATB3S | 21,300 | 23,900 | 20 | 36 x 34 x 68 | 690 |
| 4.5 HP | IEZATB4.5S | 31,200 | 35,000 | 50 | 46 x 34 x 70 | 800 |
| 5.5 HP | IEZATB5.5S | 37,100 | 41,500 | 50 | 46 x 34 x 70 | 800 |
| 9 HP | IEZATB9S | 64,200 | 72,000 | 80 | 75 x 34 x 75 | 1300 |
| 11 HP | IEZATB11S | 118,600 | 88,700 | 80 | 75 x 34 x 75 | 1400 |
| 9 HP | IEZATB9D | 62,400 | 70,000 | 80 | 75 x 34 x 75 | 1375 |
| 11 HP | IEZATB11D | 74,200 | 83,000 | 80 | 75 x 34 x 75 | 1475 |
| 18 HP | IEZATB18D | 128,400 | 144,000 | 120 | 85 x 40 x 75 | 1985 |
| 22 HP | IEZATB22D | 237,200 | 177,400 | 120 | 85 x 34 x 70 | 2500 |
Our Full Line of R454A J&M Brewery Chillers
Single and Dual Circuit Packaged Chillers with Insulated Stainless-Steel Tank
| Chiller System | Brewery Model | Capacity | Tank Capacity (Gallons) | Dimensions (L x W x H) Inches | Ship Weight (LBS) | |
|---|---|---|---|---|---|---|
| 28°F Glycol / 90°F Ambient | 33°F Glycol / 90°F Ambient | |||||
| 1 HP | PZATB1S | 10,200 | 11,400 | 20 | 36 x 34 x 68 | 685 |
| 3.5 HP | PZATB3.5S | 31,000 | 34,600 | 20 | 36 x 34 x 68 | 690 |
| 5 HP | PZATB5S | 45,200 | 50,400 | 50 | 46 x 34 x 70 | 800 |
| 6 HP | PZATB6S | 53,800 | 60,000 | 50 | 46 x 34 x 70 | 800 |
| 7.5 HP | PZATB7.5S | 70,200 | 78,300 | 50 | 75 x 34 x 75 | 1200 |
| 10.5 HP | PZATB10.5S | 93,400 | 104,300 | 80 | 75 x 34 x 75 | 1300 |
| 12.5 HP | PZATB12.5D | 115,100 | 128,400 | 80 | 75 x 34 x 75 | 1400 |
| 10 HP | PZATB10D | 90,400 | 100,800 | 80 | 75 x 34 x 75 | 1375 |
| 12 HP | PZATB12D | 107,600 | 120,000 | 120 | 75 x 34 75 | 1475 |
| 15 HP | PZATB15D | 140,400 | 156,600 | 120 | 85 x 40 x 75 | 1895 |
| 21 HP | PZATB21D | 186,00 | 208,600 | 120 | 85 x 40 x 75 | 1985 |
| 25 HP | PZATB25D | 230,200 | 256,800 | 120 | 75 x 66 x 76 | 2500 |
Single and Dual Circuit Split-System Chillers with Insulated Stainless-Steel Tank
| Chiller System | Brewery Model | Capacity | Tank Capacity (Gallons) | Dimensions (L x W x H) Inches | Ship Weight (LBS) | |
|---|---|---|---|---|---|---|
| 28°F Glycol / 90°F Ambient | 33°F Glycol / 90°F Ambient | |||||
| 1 HP | IEZATB1S | 10,200 | 11,400 | 20 | 36 x 34 x 65 | 685 |
| 3.5 HP | IEZATB3.5S | 31,000 | 34,600 | 20 | 36 x 34 x 65 | 690 |
| 5 HP | IEZATB5S | 45,200 | 50,400 | 50 | 46 x 34 x 70 | 800 |
| 6 HP | IEZATB6S | 53,800 | 60,000 | 50 | 46 x 34 x 70 | 800 |
| 7.5 HP | IEZATB7.5S | 70,200 | 78,300 | 50 | 75 x 34 x 70 | 1200 |
| 10.5 HP | IEZATB10.5S | 93,400 | 104,300 | 80 | 75 x 34 x 70 | 1300 |
| 12.5 HP | IEZATB12.5S | 115,100 | 128,400 | 80 | 75 x 34 x 70 | 1400 |
| 10 HP | IEZATB10D | 74,200 | 83,000 | 80 | 75 x 34 x 70 | 1375 |
| 12 HP | IEZATB12D | 107,600 | 120,000 | 80 | 75 x 34 x 70 | 1475 |
| 15 HP | IEZATB15D | 140,400 | 156,600 | 120 | 85 x 34 x 70 | 1895 |
| 21 HP | IEZATB21D | 186,800 | 208,600 | 120 | 85 x 34 x 70 | 1985 |
| 15 HP | IEZATB25D | 230,200 | 256,800 | 120 | 85 x 34 x 70 | 2500 |
Available Option – Outstanding Condenser Coil Protection!
Larger J&M Brewery Chiller Models Also Available
Call Us Toll-Free: (888) 539-1731
We are here to answer any questions you may have in choosing the right J&M Brewery Chiller model for your brewery cooling applications.
Happy Brewing! from J&M Fluidics
It’s All about Building a Better Product for Our Clients!
